EDAC manufactures a broad range of higher reliability electrical connectors & backshells used in a variety of industries including computer, industrial, medical and military markets.

Search Parts:

Check Distributor Stock

Categories

One of EDAC’s original connector lines, the Cardedge+ family of card edge connectors, have grown to become one the largest offerings available in the market. Available in a number of contact spacings, with multiple options for contact terminations, plating thicknesses and mounting styles, providing our customers more flexibility in their designs. With a product offering that exceeds 446,000 parts, EDAC is the world leader in Card Edge connectors.
Card Edge Connectors
EDAC Rectangular+ family of Rack and Panel connectors offer a high reliability connection, ideal where a large number of wires are interconnected to a panel. Available in seven body sizes ranging from 14 to 120 contact positions. The hermaphroditic contact design provides a gas tight connection with superior shock and vibration resistance. Ease of mating is facilitated with the use of an actuating screw and lock nut, and polarized hardware.
RECTANGULAR CONNECTORS
EDAC offers an extensive range of industry standard D-Subminiature connectors. Our D-Sub+ family are available in standard density with 9, 15, 25, 37, and 50 contacts or high density versions with 15, 26, 44, 62 and 78 contacts. Vertical and right angle orientations, along with a variety of termination, plating and mounting options are available. They’re also available in a stacked configuration.
D-Sub Connectors
EDAC’s modular and magnetic jack connectors, the E-JAX’s has standard features including single or stacked units available in multiple body styles, with or without LEDs, right angle or vertical mount and various mounting options.
Modular & Magnetic Jacks
EDAC Standard USB+ family of connectors are available in all types A, B and C in vertical or right angle orientations. USB's combine data and power in a small package. Type C offers ten times the speed of conventional USB's and will mate in either direction.
USB Connectors
HDMI connectors follow industry standards and are available in vertical or right-angle orientations. Single or dual port versions are available. These deliver high speed video transmissions resulting in very high-resolution images.
HDMI Connectors
One of EDAC’s connector lines, the Inline+ family of connectors are wire to board connectors providing a reliable and economical connection. These shrouded headers are available in a variety of positions. Right angle, vertical, SMT or through hole mounted to the PCB. These connectors are ideal for use in wire harness applications and can be customized to meet your design parameters. Compatible with leading industry connectors as drop-in replacements.
INLINE CONNECTORS
EDAC offers a broad range of box, pin, and socket header connectors in the market. Box headers are widely used for board to board, or wire to board connections. Right angle, vertical and even custom bends are available. The breakaway design allows for separation into smaller units. Pin Headers mate with socket receptacles, providing a reliable and economical BTB connection. Available in multiple contact spacing options, in single, two or three row configurations.
HEADER CONNECTORS
Enhancing one of EDAC’s original connector lines, the E-Seal family of D-Sub’s, USB’s, HDMI, Inline Wire to Wire and Wire to Board connectors, we have expanded it’s offering to include a complete range of waterproof options as part of our E-Seal series of products.
Waterproof Connectors
EDAC specializes in custom cable assemblies to meet or exceed the needs of your application. We have an extensive array of connectors to utilize in connecting your world. Various cable lengths, shielding, custom colors, customized connectors, wire gauges, jackets, latching mechanisms and custom markings are available.
Cable Assemblies
Custom Connectors

Have a question for EDAC? Connect with us. Experience makes the difference.
