317 Series

Features

  • .156" (3.96mm) Contact Spacing x .200" (5.08mm) Row Spacing
  • Accepts .062" (1.57mm) Nominal Thickness P.C. Board
  • High Profile Insulator Body, .720" (18.29mm)
  • Contact Termination .045" (1.14mm) Square Wire Wrap
  • Single or Dual Row Configurations
  • Large Variety of Mounting Options
  • Accepts between Contact and In-Contact Polarizing Keys
  • Pre-assembled Card Guides are available
  • RoHS Compliant


Specifications

  • Insulator Material: UL 94V-0 Diallyl Phthalate, Green Color
  • Contact Material: Copper Alloy
  • Contact Plating: Gold Plating with Nickel underplating all over
  • Current Rating: 5 Amperes
  • Contact Resistance: 10 milliohms maximum
  • Dielectric Withstand Voltage: 1800 VAC rms at sea level between adjacent contacts
  • Insulation Resistance: 5000 Megaohms minimum
  • Operating Temperature: -65°C to +125°C
  • Insertion Force: 16oz (4.45N) maximum per contact pair when tested with .070" (1.78mm) thick gauge
  • Withdrawal Force: 1oz (0.28N) minimum per contact pair when tested with .054" (1.37mm) thick gauge



Notes

Ordering Guide:


317


Card Edge Connector | 0.156" (3.96mm) Pitch | 0.200" (5.08mm) Row Spacing


OR

Loading Parts


Part #

Position

Gender

Material

Color

Rows

Contact Description

Contact Tail Size

Contact Tail Length

Mounting Option

Datasheet

3D Model

317-009-542-602 - Card Edge Connector
317-009-542-602 - Card Edge Connector
317-009-542-602 9 Female UL 94V-0 Diallyl Phthalate Green Single Row Wire Wrap .045" Square (1.14mm Square) .750" (19.05mm) .144" (3.66mm) Dia. Mounting Holes
317-009-542-603 - Card Edge Connector
317-009-542-603 - Card Edge Connector
317-009-542-603 9 Female UL 94V-0 Diallyl Phthalate Green Single Row Wire Wrap .045" Square (1.14mm Square) .750" (19.05mm) .116" (2.95mm) I.D. Floating Eyelets
317-009-542-604 - Card Edge Connector
317-009-542-604 - Card Edge Connector
317-009-542-604 9 Female UL 94V-0 Diallyl Phthalate Green Single Row Wire Wrap .045" Square (1.14mm Square) .750" (19.05mm) .156" (3.96mm) Dia. Mounting Holes
317-009-542-607 - Card Edge Connector
317-009-542-607 - Card Edge Connector
317-009-542-607 9 Female UL 94V-0 Diallyl Phthalate Green Single Row Wire Wrap .045" Square (1.14mm Square) .750" (19.05mm) M3-0.5 Metric Threaded Inserts
317-009-542-608 - Card Edge Connector
317-009-542-608 - Card Edge Connector
317-009-542-608 9 Female UL 94V-0 Diallyl Phthalate Green Single Row Wire Wrap .045" Square (1.14mm Square) .750" (19.05mm) #4-40 Unified Threaded Inserts
317-009-542-678 - Card Edge Connector
317-009-542-678 - Card Edge Connector
317-009-542-678 9 Female UL 94V-0 Diallyl Phthalate Green Single Row Wire Wrap .045" Square (1.14mm Square) .750" (19.05mm) In-Line Card Guides
317-010-541-601 - Card Edge Connector
317-010-541-601 - Card Edge Connector
317-010-541-601 10 Female UL 94V-0 Diallyl Phthalate Green Single Row Wire Wrap .045" Square (1.14mm Square) .750" (19.05mm) No Mounting Lugs
317-010-541-602 - Card Edge Connector
317-010-541-602 - Card Edge Connector
317-010-541-602 10 Female UL 94V-0 Diallyl Phthalate Green Single Row Wire Wrap .045" Square (1.14mm Square) .750" (19.05mm) .144" (3.66mm) Dia. Mounting Holes
317-010-541-603 - Card Edge Connector
317-010-541-603 - Card Edge Connector
317-010-541-603 10 Female UL 94V-0 Diallyl Phthalate Green Single Row Wire Wrap .045" Square (1.14mm Square) .750" (19.05mm) .116" (2.95mm) I.D. Floating Eyelets
317-010-541-604 - Card Edge Connector
317-010-541-604 - Card Edge Connector
317-010-541-604 10 Female UL 94V-0 Diallyl Phthalate Green Single Row Wire Wrap .045" Square (1.14mm Square) .750" (19.05mm) .156" (3.96mm) Dia. Mounting Holes
317-010-541-607 - Card Edge Connector
317-010-541-607 - Card Edge Connector
317-010-541-607 10 Female UL 94V-0 Diallyl Phthalate Green Single Row Wire Wrap .045" Square (1.14mm Square) .750" (19.05mm) M3-0.5 Metric Threaded Inserts
317-010-541-608 - Card Edge Connector
317-010-541-608 - Card Edge Connector
317-010-541-608 10 Female UL 94V-0 Diallyl Phthalate Green Single Row Wire Wrap .045" Square (1.14mm Square) .750" (19.05mm) #4-40 Unified Threaded Inserts
317-010-541-678 - Card Edge Connector
317-010-541-678 - Card Edge Connector
317-010-541-678 10 Female UL 94V-0 Diallyl Phthalate Green Single Row Wire Wrap .045" Square (1.14mm Square) .750" (19.05mm) In-Line Card Guides
317-010-542-601 - Card Edge Connector
317-010-542-601 - Card Edge Connector
317-010-542-601 10 Female UL 94V-0 Diallyl Phthalate Green Single Row Wire Wrap .045" Square (1.14mm Square) .750" (19.05mm) No Mounting Lugs
317-010-542-602 - Card Edge Connector
317-010-542-602 - Card Edge Connector
317-010-542-602 10 Female UL 94V-0 Diallyl Phthalate Green Single Row Wire Wrap .045" Square (1.14mm Square) .750" (19.05mm) .144" (3.66mm) Dia. Mounting Holes
317-010-542-603 - Card Edge Connector
317-010-542-603 - Card Edge Connector
317-010-542-603 10 Female UL 94V-0 Diallyl Phthalate Green Single Row Wire Wrap .045" Square (1.14mm Square) .750" (19.05mm) .116" (2.95mm) I.D. Floating Eyelets
317-010-542-604 - Card Edge Connector
317-010-542-604 - Card Edge Connector
317-010-542-604 10 Female UL 94V-0 Diallyl Phthalate Green Single Row Wire Wrap .045" Square (1.14mm Square) .750" (19.05mm) .156" (3.96mm) Dia. Mounting Holes
317-010-542-607 - Card Edge Connector
317-010-542-607 - Card Edge Connector
317-010-542-607 10 Female UL 94V-0 Diallyl Phthalate Green Single Row Wire Wrap .045" Square (1.14mm Square) .750" (19.05mm) M3-0.5 Metric Threaded Inserts
317-010-542-608 - Card Edge Connector
317-010-542-608 - Card Edge Connector
317-010-542-608 10 Female UL 94V-0 Diallyl Phthalate Green Single Row Wire Wrap .045" Square (1.14mm Square) .750" (19.05mm) #4-40 Unified Threaded Inserts
317-010-542-678 - Card Edge Connector
317-010-542-678 - Card Edge Connector
317-010-542-678 10 Female UL 94V-0 Diallyl Phthalate Green Single Row Wire Wrap .045" Square (1.14mm Square) .750" (19.05mm) In-Line Card Guides
317-011-541-601 - Card Edge Connector
317-011-541-601 - Card Edge Connector
317-011-541-601 11 Female UL 94V-0 Diallyl Phthalate Green Single Row Wire Wrap .045" Square (1.14mm Square) .750" (19.05mm) No Mounting Lugs
317-011-541-602 - Card Edge Connector
317-011-541-602 - Card Edge Connector
317-011-541-602 11 Female UL 94V-0 Diallyl Phthalate Green Single Row Wire Wrap .045" Square (1.14mm Square) .750" (19.05mm) .144" (3.66mm) Dia. Mounting Holes
317-011-541-603 - Card Edge Connector
317-011-541-603 - Card Edge Connector
317-011-541-603 11 Female UL 94V-0 Diallyl Phthalate Green Single Row Wire Wrap .045" Square (1.14mm Square) .750" (19.05mm) .116" (2.95mm) I.D. Floating Eyelets
317-011-541-604 - Card Edge Connector
317-011-541-604 - Card Edge Connector
317-011-541-604 11 Female UL 94V-0 Diallyl Phthalate Green Single Row Wire Wrap .045" Square (1.14mm Square) .750" (19.05mm) .156" (3.96mm) Dia. Mounting Holes
317-011-541-607 - Card Edge Connector
317-011-541-607 - Card Edge Connector
317-011-541-607 11 Female UL 94V-0 Diallyl Phthalate Green Single Row Wire Wrap .045" Square (1.14mm Square) .750" (19.05mm) M3-0.5 Metric Threaded Inserts
317-011-541-608 - Card Edge Connector
317-011-541-608 - Card Edge Connector
317-011-541-608 11 Female UL 94V-0 Diallyl Phthalate Green Single Row Wire Wrap .045" Square (1.14mm Square) .750" (19.05mm) #4-40 Unified Threaded Inserts
317-011-541-678 - Card Edge Connector
317-011-541-678 - Card Edge Connector
317-011-541-678 11 Female UL 94V-0 Diallyl Phthalate Green Single Row Wire Wrap .045" Square (1.14mm Square) .750" (19.05mm) In-Line Card Guides
317-011-542-601 - Card Edge Connector
317-011-542-601 - Card Edge Connector
317-011-542-601 11 Female UL 94V-0 Diallyl Phthalate Green Single Row Wire Wrap .045" Square (1.14mm Square) .750" (19.05mm) No Mounting Lugs
317-011-542-602 - Card Edge Connector
317-011-542-602 - Card Edge Connector
317-011-542-602 11 Female UL 94V-0 Diallyl Phthalate Green Single Row Wire Wrap .045" Square (1.14mm Square) .750" (19.05mm) .144" (3.66mm) Dia. Mounting Holes
317-011-542-603 - Card Edge Connector
317-011-542-603 - Card Edge Connector
317-011-542-603 11 Female UL 94V-0 Diallyl Phthalate Green Single Row Wire Wrap .045" Square (1.14mm Square) .750" (19.05mm) .116" (2.95mm) I.D. Floating Eyelets
317-011-542-604 - Card Edge Connector
317-011-542-604 - Card Edge Connector
317-011-542-604 11 Female UL 94V-0 Diallyl Phthalate Green Single Row Wire Wrap .045" Square (1.14mm Square) .750" (19.05mm) .156" (3.96mm) Dia. Mounting Holes
317-011-542-607 - Card Edge Connector
317-011-542-607 - Card Edge Connector
317-011-542-607 11 Female UL 94V-0 Diallyl Phthalate Green Single Row Wire Wrap .045" Square (1.14mm Square) .750" (19.05mm) M3-0.5 Metric Threaded Inserts
317-011-542-608 - Card Edge Connector
317-011-542-608 - Card Edge Connector
317-011-542-608 11 Female UL 94V-0 Diallyl Phthalate Green Single Row Wire Wrap .045" Square (1.14mm Square) .750" (19.05mm) #4-40 Unified Threaded Inserts
317-011-542-678 - Card Edge Connector
317-011-542-678 - Card Edge Connector
317-011-542-678 11 Female UL 94V-0 Diallyl Phthalate Green Single Row Wire Wrap .045" Square (1.14mm Square) .750" (19.05mm) In-Line Card Guides
317-012-540-801 - Card Edge Connector
317-012-540-801 - Card Edge Connector
317-012-540-801 12 Female UL 94V-0 Diallyl Phthalate Green Dual Row Wire Wrap .045" Square (1.14mm Square) .750" (19.05mm) No Mounting Lugs
317-012-540-802 - Card Edge Connector
317-012-540-802 - Card Edge Connector
317-012-540-802 12 Female UL 94V-0 Diallyl Phthalate Green Dual Row Wire Wrap .045" Square (1.14mm Square) .750" (19.05mm) .144" (3.66mm) Dia. Mounting Holes
317-012-540-803 - Card Edge Connector
317-012-540-803 - Card Edge Connector
317-012-540-803 12 Female UL 94V-0 Diallyl Phthalate Green Dual Row Wire Wrap .045" Square (1.14mm Square) .750" (19.05mm) .116" (2.95mm) I.D. Floating Eyelets
317-012-540-804 - Card Edge Connector
317-012-540-804 - Card Edge Connector
317-012-540-804 12 Female UL 94V-0 Diallyl Phthalate Green Dual Row Wire Wrap .045" Square (1.14mm Square) .750" (19.05mm) .156" (3.96mm) Dia. Mounting Holes
317-012-540-807 - Card Edge Connector
317-012-540-807 - Card Edge Connector
317-012-540-807 12 Female UL 94V-0 Diallyl Phthalate Green Dual Row Wire Wrap .045" Square (1.14mm Square) .750" (19.05mm) M3-0.5 Metric Threaded Inserts
317-012-540-808 - Card Edge Connector
317-012-540-808 - Card Edge Connector
317-012-540-808 12 Female UL 94V-0 Diallyl Phthalate Green Dual Row Wire Wrap .045" Square (1.14mm Square) .750" (19.05mm) #4-40 Unified Threaded Inserts
317-012-540-878 - Card Edge Connector
317-012-540-878 - Card Edge Connector
317-012-540-878 12 Female UL 94V-0 Diallyl Phthalate Green Dual Row Wire Wrap .045" Square (1.14mm Square) .750" (19.05mm) In-Line Card Guides
317-012-541-601 - Card Edge Connector
317-012-541-601 - Card Edge Connector
317-012-541-601 12 Female UL 94V-0 Diallyl Phthalate Green Single Row Wire Wrap .045" Square (1.14mm Square) .750" (19.05mm) No Mounting Lugs
317-012-541-602 - Card Edge Connector
317-012-541-602 - Card Edge Connector
317-012-541-602 12 Female UL 94V-0 Diallyl Phthalate Green Single Row Wire Wrap .045" Square (1.14mm Square) .750" (19.05mm) .144" (3.66mm) Dia. Mounting Holes
317-012-541-603 - Card Edge Connector
317-012-541-603 - Card Edge Connector
317-012-541-603 12 Female UL 94V-0 Diallyl Phthalate Green Single Row Wire Wrap .045" Square (1.14mm Square) .750" (19.05mm) .116" (2.95mm) I.D. Floating Eyelets
317-012-541-604 - Card Edge Connector
317-012-541-604 - Card Edge Connector
317-012-541-604 12 Female UL 94V-0 Diallyl Phthalate Green Single Row Wire Wrap .045" Square (1.14mm Square) .750" (19.05mm) .156" (3.96mm) Dia. Mounting Holes
317-012-541-607 - Card Edge Connector
317-012-541-607 - Card Edge Connector
317-012-541-607 12 Female UL 94V-0 Diallyl Phthalate Green Single Row Wire Wrap .045" Square (1.14mm Square) .750" (19.05mm) M3-0.5 Metric Threaded Inserts
317-012-541-608 - Card Edge Connector
317-012-541-608 - Card Edge Connector
317-012-541-608 12 Female UL 94V-0 Diallyl Phthalate Green Single Row Wire Wrap .045" Square (1.14mm Square) .750" (19.05mm) #4-40 Unified Threaded Inserts
317-012-541-678 - Card Edge Connector
317-012-541-678 - Card Edge Connector
317-012-541-678 12 Female UL 94V-0 Diallyl Phthalate Green Single Row Wire Wrap .045" Square (1.14mm Square) .750" (19.05mm) In-Line Card Guides
317-012-542-601 - Card Edge Connector
317-012-542-601 - Card Edge Connector
317-012-542-601 12 Female UL 94V-0 Diallyl Phthalate Green Single Row Wire Wrap .045" Square (1.14mm Square) .750" (19.05mm) No Mounting Lugs
317-012-542-602 - Card Edge Connector
317-012-542-602 - Card Edge Connector
317-012-542-602 12 Female UL 94V-0 Diallyl Phthalate Green Single Row Wire Wrap .045" Square (1.14mm Square) .750" (19.05mm) .144" (3.66mm) Dia. Mounting Holes
