J21 Series

Features

  • Top performance for high speed networking, voice, and data applications
  • Meets FCC Part 68, Subpart F requirements
  • Applications: Telecommunications, consumer, energy, industrial, medical, process control, ruggedized, transportation
  • RoHS Compliant


Specifications

  • Housing Material: PBT or Nylon
  • Contact Material: Phosphor Bronze
  • Contact Plating: Gold plating on contact area and tin plating on tails with nickel underplating all over
  • Current Rating: 1.5A @25°C
  • Voltage Rating: 125V AC
  • Contact Resistance: 20 m? maximum
  • Dielectric Withstanding Voltage: 1000V AC
  • Insulation Resistance: 500 M? minimum
  • Durability: 750 cycles minimum
  • Operating Temperature: -40°C to +85°C
  • Wave Soldering Process: 260°C ± 5°C, 5~10 Seconds



Notes

Ordering Guide:


J21


SINGLE PORT RJ11, VERTICAL PCB MOUNT, NON-SHIELDED, 6.35mm FOOTPRINT


OR

Loading Parts


Part #

Position

Housing Type

No. of Ports

No. of Contacts per Port

Contact Plating

Contact Tail Type

Housing Material

Left LED Color

Right LED Color

Shielding

Port Type

Mounting Options

Datasheet

3D Model

J21014421N00033 - Modular Jack Connector
J21014421N00033 - Modular Jack Connector
J21014421N00033 Code 21 1 Port 4P4C Gold Flash Plating Vertical PCB Nylon No LED No LED No Shield Single Row (Vertical) Panel Stops/Ears & Boardlocks
J21014421P00033 - Modular Jack Connector
J21014421P00033 - Modular Jack Connector
J21014421P00033 Code 21 1 Port 4P4C Gold Flash Plating Vertical PCB PBT No LED No LED No Shield Single Row (Vertical) Panel Stops/Ears & Boardlocks
J21014431N00033 - Modular Jack Connector
J21014431N00033 - Modular Jack Connector
J21014431N00033 Code 21 1 Port 4P4C 15 Microinches of Gold Vertical PCB Nylon No LED No LED No Shield Single Row (Vertical) Panel Stops/Ears & Boardlocks
J21014431P00033 - Modular Jack Connector
J21014431P00033 - Modular Jack Connector
J21014431P00033 Code 21 1 Port 4P4C 15 Microinches of Gold Vertical PCB PBT No LED No LED No Shield Single Row (Vertical) Panel Stops/Ears & Boardlocks
J21014461N00033 - Modular Jack Connector
J21014461N00033 - Modular Jack Connector
J21014461N00033 Code 21 1 Port 4P4C 30 Microinches of Gold Vertical PCB Nylon No LED No LED No Shield Single Row (Vertical) Panel Stops/Ears & Boardlocks
J21014461P00033 - Modular Jack Connector
J21014461P00033 - Modular Jack Connector
J21014461P00033 Code 21 1 Port 4P4C 30 Microinches of Gold Vertical PCB PBT No LED No LED No Shield Single Row (Vertical) Panel Stops/Ears & Boardlocks
J21014491N00033 - Modular Jack Connector
J21014491N00033 - Modular Jack Connector
J21014491N00033 Code 21 1 Port 4P4C 50 Microinches of Gold Vertical PCB Nylon No LED No LED No Shield Single Row (Vertical) Panel Stops/Ears & Boardlocks
J21014491P00033 - Modular Jack Connector
J21014491P00033 - Modular Jack Connector
J21014491P00033 Code 21 1 Port 4P4C 50 Microinches of Gold Vertical PCB PBT No LED No LED No Shield Single Row (Vertical) Panel Stops/Ears & Boardlocks
