690T Series

Features

  • Up to 480 Mbps communication speed for standard USB 2.0
  • Up to 5 Gbps communication speed for standard USB 3.0
  • Industry standard plug and play technology - 'Hot Pluggable'
  • Compatible with synchronous and asynchronous data transfer
  • Data and power combined in one small package
  • RoHS compliant


Specifications

  • Insulator Material: UL-94V-0 Thermoplastic
  • Contact Material: Copper Alloy
  • Contact Plating: Nickel under plating with gold plating on contact areas and tin plating on tails
  • Shell Material: Brass with nickel plating
  • Insertion Force: 35N maximum
  • Withdrawal Force: 3N minimum 2.0 Mini / 8N minimum 2.0 Micro



Notes

Ordering Guide:


690T

Check Inventory
3D Models
Resource Center
Compliance
Custom Connectors

USB MINI & MICRO TYPE-B RECEPTACLES - RIGHT ANGLE SMT

Filter

OR

Loading Parts


Part #

Gender

Connector Type

Contact Plating

Contact Description

Mounting Option

Connector Option

Material

Insulator Color

Datasheet

3D Model
690T205-16B-211 - USB Type-B Mini connector
690T205-16B-211 - USB Type-B Mini connector
 690T205-16B-211
   Order Samples    Check Distributor Stock
Receptacle USB 2.0 Mini-B 2 to 5 Microinches of Gold Plating Right Angle SMT Plastic Posts & 4 SMT Grounding Tabs No Tabs on Leading Edge LCP Black
690T205-26B-211 - USB Type-B Mini connector
690T205-26B-211 - USB Type-B Mini connector
 690T205-26B-211
   Order Samples    Check Distributor Stock
Receptacle USB 2.0 Mini-B Gold Flash Plating Right Angle SMT Plastic Posts & 4 SMT Grounding Tabs No Tabs on Leading Edge LCP Black
690T205-36B-211 - USB Type-B Mini connector
690T205-36B-211 - USB Type-B Mini connector
 690T205-36B-211
   Order Samples    Check Distributor Stock
Receptacle USB 2.0 Mini-B 5 to 10 Microinches of Gold Plating Right Angle SMT Plastic Posts & 4 SMT Grounding Tabs No Tabs on Leading Edge LCP Black
690T205-56B-211 - USB Type-B Mini connector
690T205-56B-211 - USB Type-B Mini connector
 690T205-56B-211
   Order Samples    Check Distributor Stock
Receptacle USB 2.0 Mini-B 15 Microinches of Gold Plating Right Angle SMT Plastic Posts & 4 SMT Grounding Tabs No Tabs on Leading Edge LCP Black
690T205-66B-211 - USB Type-B Mini connector
690T205-66B-211 - USB Type-B Mini connector
 690T205-66B-211
   Order Samples    Check Distributor Stock
Receptacle USB 2.0 Mini-B 30 Microinches of Gold Plating Right Angle SMT Plastic Posts & 4 SMT Grounding Tabs No Tabs on Leading Edge LCP Black
690T505-162-010 - USB Type-B Mini connector
690T505-162-010 - USB Type-B Mini connector
 690T505-162-010
   Order Samples    Check Distributor Stock
Receptacle USB 2.0 Micro-B 2 to 5 Microinches of Gold Plating Right Angle SMT 4 Through Hole Grounding Tabs Tabs on Leading Edge LCP White/Natural
690T505-162-011 - USB Type-B Mini connector
690T505-162-011 - USB Type-B Mini connector
 690T505-162-011
   Order Samples    Check Distributor Stock
Receptacle USB 2.0 Micro-B 2 to 5 Microinches of Gold Plating Right Angle SMT 4 Through Hole Grounding Tabs Tabs on Leading Edge LCP Black
690T505-262-010 - USB Type-B Mini connector
690T505-262-010 - USB Type-B Mini connector
 690T505-262-010
   Order Samples    Check Distributor Stock
Receptacle USB 2.0 Micro-B Gold Flash Plating Right Angle SMT 4 Through Hole Grounding Tabs Tabs on Leading Edge LCP White/Natural
690T505-262-011 - USB Type-B Mini connector
690T505-262-011 - USB Type-B Mini connector
 690T505-262-011
   Order Samples    Check Distributor Stock
Receptacle USB 2.0 Micro-B Gold Flash Plating Right Angle SMT 4 Through Hole Grounding Tabs Tabs on Leading Edge LCP Black
690T505-362-010 - USB Type-B Mini connector
690T505-362-010 - USB Type-B Mini connector
 690T505-362-010
   Order Samples    Check Distributor Stock
Receptacle USB 2.0 Micro-B 5 to 10 Microinches of Gold Plating Right Angle SMT 4 Through Hole Grounding Tabs Tabs on Leading Edge LCP White/Natural
690T505-362-011 - USB Type-B Mini connector
690T505-362-011 - USB Type-B Mini connector
 690T505-362-011
   Order Samples    Check Distributor Stock
Receptacle USB 2.0 Micro-B 5 to 10 Microinches of Gold Plating Right Angle SMT 4 Through Hole Grounding Tabs Tabs on Leading Edge LCP Black
690T505-562-010 - USB Type-B Mini connector
690T505-562-010 - USB Type-B Mini connector
 690T505-562-010
   Order Samples    Check Distributor Stock
Receptacle USB 2.0 Micro-B 15 Microinches of Gold Plating Right Angle SMT 4 Through Hole Grounding Tabs Tabs on Leading Edge LCP White/Natural
690T505-562-011 - USB Type-B Mini connector
690T505-562-011 - USB Type-B Mini connector
 690T505-562-011
   Order Samples    Check Distributor Stock
Receptacle USB 2.0 Micro-B 15 Microinches of Gold Plating Right Angle SMT 4 Through Hole Grounding Tabs Tabs on Leading Edge LCP Black
690T505-662-010 - USB Type-B Mini connector
690T505-662-010 - USB Type-B Mini connector
 690T505-662-010
   Order Samples    Check Distributor Stock
Receptacle USB 2.0 Micro-B 30 Microinches of Gold Plating Right Angle SMT 4 Through Hole Grounding Tabs Tabs on Leading Edge LCP White/Natural
690T505-662-011 - USB Type-B Mini connector
690T505-662-011 - USB Type-B Mini connector
 690T505-662-011
   Order Samples    Check Distributor Stock
Receptacle USB 2.0 Micro-B 30 Microinches of Gold Plating Right Angle SMT 4 Through Hole Grounding Tabs Tabs on Leading Edge LCP Black
