567 Series

E-SEAL2222

Features

  • 5.0mm x 5.9mm Pitch, Rated Current: 8A max
  • Splashproof Solution available in 1, 2, 3, 4, 6, or 9 positions
  • Available in Wire-to-Wire Options
  • True Crimp and Poke Solution with various sized wire seals available
  • Available with wire already installed
  • Splash Proof Grade IP52 (JIS C0920) Certified


Specifications

  • No. of Positions : 1, 2, 3, 4, 6, or 9
  • Pitch : 5.0mm x 5.9mm
  • Rated Voltage : 300V
  • Rated Current : 8A max
  • Withstanding Voltage : 1700V AC (rms)
  • Contact Resistance : 10 m? max
  • Insulation Resistance : 1000 M? min./DC500V
  • Temperature Range : -40°C to +105°C



Notes





E-Seal | In-Line Waterproof Connectors


OR

Loading Parts


Part #

Position

Contact description

Type

Housing style

Gender

no image
567-001-000-310 1 No Contacts (Only for crimp contacts) Wire to wire White male housing for crimp contacts Male
no image
567-001-000-410 1 No Contacts (Only for crimp contacts) Wire to wire White female housing for crimp contacts Female
no image
567-002-000-310 2 No Contacts (Only for crimp contacts) Wire to wire White male housing for crimp contacts Male
no image
567-002-000-410 2 No Contacts (Only for crimp contacts) Wire to wire White female housing for crimp contacts Female
no image
567-003-000-310 3 No Contacts (Only for crimp contacts) Wire to wire White male housing for crimp contacts Male
no image
567-003-000-410 3 No Contacts (Only for crimp contacts) Wire to wire White female housing for crimp contacts Female
no image
567-004-000-310 4 No Contacts (Only for crimp contacts) Wire to wire White male housing for crimp contacts Male
no image
567-004-000-410 4 No Contacts (Only for crimp contacts) Wire to wire White female housing for crimp contacts Female
no image
567-006-000-310 6 No Contacts (Only for crimp contacts) Wire to wire White male housing for crimp contacts Male
no image
567-006-000-410 6 No Contacts (Only for crimp contacts) Wire to wire White female housing for crimp contacts Female
no image
567-009-000-310 9 No Contacts (Only for crimp contacts) Wire to wire White male housing for crimp contacts Male
no image
567-009-000-410 9 No Contacts (Only for crimp contacts) Wire to wire White female housing for crimp contacts Female
